UMPX-12 Portable Step Up Voltage Frequency Converter
By PowerXchanger
Input Voltage and Output Capacity
The converter’s output capacity depends on the input voltage. Selecting the correct world plug type
ensures maximum performance.
| I/P | Level of Full-Load (100%) | O/P Current |
|---|---|---|
| 100V | 1890VA / 1700W | 8.6A / 7.7A |
| 110V | 2100VA / 1890W | 9.5A / 8.6A |
| 120V | 2200VA / 1980W | 10.0A / 9.0A |
| 130V | 2280VA / 2050W | 10.4A / 9.3A |
| 140V | 2370VA / 2130W | 10.8A / 9.7A |
| 150V | 2490VA / 2240W | 11.3A / 10.2A |
| 160V | 2610VA / 2350W | 11.9A / 10.7A |
| 170V | 2780VA / 2500W | 12.6A / 11.4A |
| 180V | 3000VA / 2700W | 13.6A / 12.5A |
| 190V | 3000VA / 2700W | 13.6A / 12.5A |
| 200V | 3000VA / 2700W | 13.6A / 12.5A |
| 210V | 3000VA / 2700W | 13.6A / 12.5A |
| 220V | 3000VA / 2700W | 13.6A / 12.5A |
| 230V | 3000VA / 2700W | 13.6A / 12.5A |
| 240V | 3000VA / 2700W | 13.6A / 12.5A |
